114 Expansion Cards
15
If you installed a network adapter card and want to turn off the integrated network adapter:
a
Enter system setup, select
Network Controller
and change the setting to
Off
(see "Entering
System Setup" on page 280).
b
Connect the network cable to the network adapter card’s connectors. Do not connect the network
cable to the integrated network connector on the back panel of the computer.
NOTICE: If you disable the integrated network adapter, you will not have AMT functionality.
16
Install any drivers required for the card as described in the card documentation.
Removing a PCI Card From the Riser-Card Cage
1
Follow the procedures in "Before You Begin" on page 21.
2
Remove the computer cover (see "Removing the Computer Cover" on page 90).
3
Remove the riser-card cage:
a
Check any cables connected to cards through the back panel openings. Disconnect any cables that
will not reach the riser-card cage once they are removed from the computer.
b
Gently pull on the handle and lift the riser-card cage up and away from the computer.
4
Press in on the tab to raise the card-retention latch.
1 riser-card cage
2 handle
1
2
