248 Drives
Power Cable Connectors
Connecting and Disconnecting Drive Cables
When connecting and disconnecting a SATA data cable, hold the cable by the black connector at each
end. When removing a cable with a pull-tab, grasp the colored pull-tab and pull until the connector
detaches.
Hard Drive
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the
Product
Information Guide
.
1power cable
2 power input connector
1
2
