Small Form Factor Computer 169
4
Grip the sides of the computer cover and pivot the cover up using the bottom hinges as leverage
points.
5
Remove the cover from the hinge tabs and set it aside on a soft nonabrasive surface.
CAUTION: Graphics card heat sinks can become very hot during normal operation. Ensure that a graphics card
heat sink has had sufficient time to cool before you touch it.
Inside Your Computer
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the
Product
Information Guide
.
CAUTION: To avoid electrical shock, always unplug your computer from the electrical outlet before removing
the computer cover.
1 security cable slot
2 cover release latch
3 computer cover
2
1
3
