Dell OptiPlex 755 - Connecting Drive Cables; Data Interface Connectors; Power Cable Connectors

54 Drives
Connecting Drive Cables
When you install a drive, you connect two cables—a DC power cable and a data interface cable—to the
back of the drive.
Data Interface Connectors
Power Cable Connectors
SATA Connector
1 data interface cable connector 2 data interface connector
1 power cable 2 power input connector
