Dell OptiPlex 755 - Replacing the I;O Panel

154 I/O Panel
Replacing the I/O Panel
To replace the I/O panel, follow the removal procedures in the reverse order.
NOTE: Use the guides on the I/O panel bracket to help position the I/O panel in place and use the notch on the I/O
panel bracket to help seat the card.
1 securing screw
2 I/O panel
3 I/O cable connector
4 I/O connector pull loop
2
1
3
4
