Power Supply 159

DC Power Connector P2

23 +5 VDC Red

24 GND Black

*Use 22-AWG wire instead of 18-AWG

wire.

Pin Number Signal Name 18-AWG Wire

1GNDBlack

2GNDBlack

3 +12 VDC Yellow

4 +12 VDC Yellow

Pin

Number

Signal name 18-AWG

Wire

3

1

4

2
