Dell OptiPlex 755 - Page 158

158 Power Supply
6+5 VDC Red
7GND Black
8 PS_PWRGOOD* Gray
9P5AUX Purple
10 +12 VDC White
11 +12 VDC White
12 +3.3 VDC Orange
13 +3.3 VDC/SE Orange
14 +12 VDC* Blue
15 GND Black
16 PWR_PS_ON* Green
17 GND Black
18 GND Black
19 GND Black
20 NC NC
21 +5 VDC Red
22 +5 VDC Red
Pin
Number
Signal name 18-AWG
Wire
