136 Drives
Installing a Floppy Drive
1
If you are installing a new floppy drive
a
Remove the drive inserts (see "Removing Drive Inserts" on page 129).
b
Pull to remove the floppy drive insert that should be installed in the drive bay.
c
Remove the four shoulder screws from the drive panel insert.
2
If you are replacing an existing floppy drive:
Remove the four shoulder screws from the existing drive or media card reader.
3
Insert the four shoulder screws into the sides of the new floppy drive and tighten them.
1drive insert
1
