70 Drives
Installing an Optical Drive
1
Follow the procedures in "Before You Begin" on page 21.
2
Remove the computer cover (see "Removing the Computer Cover" on page 27).
3
If you are replacing an optical drive, remove the shoulder screws from the existing drive and attach the
screws to the replacement drive.
4
If you are installing a new optical drive, remove the drive-panel insert, remove the shoulder screws from
the inside of the drive-panel insert, and attach the screws to the new drive.
1 optical drive 2 drive release latch
1
2
