Drives 71
5 Check the documentation that accompanied the drive to verify that the drive is configured for your
computer.
6 Align the shoulder screws on the optical drive with the shoulder screw slots, and slide the drive into the
bay until it clicks into place.
1 optical drive 2 shoulder screws (3) 3 shoulder screw slots (2)
1
2
3
