196 Drives
Connecting Drive Cables
When you install a drive, you connect two cables (a DC power cable and a data interface cable) to the
back of the drive.
Data Interface Connectors
Power Cable Connectors
Connecting and Disconnecting Drive Cables
When removing an cable with a pull-tab, grasp the colored pull-tab and pull until the connector
detaches.
Serial ATA (SATA) Connector
1 data interface cable connector
2 data interface connector
1power cable
2 power input connector
1
2
1
2
