126 Expansion Cards
6 Replace the riser.
7 Replace the computer cover (see "Replacing the Computer Cover" on page 317).
8 Boot your computer and enter system setup (see "Entering System Setup" on page 280). Use the
esata option to enable the eSATA drive.
1 riser-card cage 3 riser cards (2)
2 slots 4 system board connectors (2)
1
2
4
3
