144 Drives
4
Attach the bracket to the new drive by snapping it onto the drive.
5
Connect the power and data cables to the drive.
6
Locate the correct slot for the drive, and slide the drive into the bay until it clicks into place.
1 hard drive
2 release tabs (2)
3 plastic hard drive bracket
1 securing tabs (2) 3 release tabs (2)
2drive 4plastic hard drive bracket
1
2
3
1
2
3
4
