222 Power Supply

7GND Black

8PS_PWRGOOD*Gray

9P5AUX Purple

10 V_12P0_DIG Yellow

11 V_12P0_DIG Yellow

12 +3.3 V Orange

13

(optional)

+3.3V Orange

14 -12 V* Blue

15 GND Black

16 PWR_PS_ON Green

17 GND Black

18 GND Black

19 GND Black

20 NC NC

21 VCC (+5V) Red

22 VCC (+5V) Red

Pin

Number

Signal Name 18-

AWG

Wire
