242 Ultra Small Form Factor Computer Specifications
Audio
Type ADI 1984 High Definition Audio
Stereo conversion 24-bit analog-to-digital; 24-bit digital-to-analog
Controllers
Drives one serial ATA controller supporting one device
Expansion Bus
Bus type SATA 1.0a and 2.0;
USB 2.0
Bus speed SATA: 1.5 and 3.0 Gbps;
USB: 480 Mbps
Drives
Internal/External one D-module bay for an optical drive, second hard drive, or floppy
drive
one bay for a 3.5-inch hard drive
Connectors
External connectors:
Serial
9-pin connector; 16550C-compatible
Parallel
25-pin connector (bidirectional)
Video
28-pin DVI connector
Network adapter
RJ45 connector
USB
two front-panel and five back panel USB 2.0–compliant connectors
Audio
two back panel connectors for line-in and line-out; two front-panel
connectors for headphones and microphone
System board connectors:
SATA
7-pin connector
Fan
one 3-pin and two 5-pin connectors
