262 Processor
4
Remove the heat sink:
a
Press the release lever on the retention base until the heat sink is released.
b
Gently lift the heat sink from the processor.
c
Lay the heat sink down on its top, with the thermal grease facing upward.
NOTICE: Unless a new heat sink is required for the new processor, reuse the original heat sink assembly when
you replace the processor.
5
Pull the release lever straight up until the processor is released, and then remove the processor from the
socket.
1 top of heat sink
2 heat sink
3 retention base
4 release tab
2
4
3
1
