Dell OptiPlex 755 - Page 65

Drives 65
3 Align the shoulder screws on the floppy drive with the shoulder screw slots, and gently slide it into the
bay until it clicks into place.
4 Attach the power and data cables to the floppy drive and to the system board.
1 floppy drive 2 shoulder screws (4) 3 shoulder screw slots (2)
1
2
3
