82 Power Supply
4 +5 VDC Red
5GND Black
6 +5 VDC Red
7GND Black
8 PS_PWRGOOD Gray
9P5AUX Purple
10 V_12P0_DIG White
11 V_12P0_DIG White
12 +3.3 VDC Orange
13 +3.3VDC/SE* Orange
14 -12 VDC Blue
15 GND Black
16 PWR_PS_ON Green
17 GND Black
18 GND Black
19 GND Black
20 NC NC
21 +5 VDC Red
22 +5 VDC Red
Pin Number Signal name 18-AWG Wire
