Desktop Computer Specifications 99
connector size
164 pins (x16)
connector data width
(maximum)
16 PCI Express lanes (x16)
PCI and PCI Express: with
optional, full-height PCI Express
riser-card cage, supporting both
low-profile and full-height cards
PCI
connectors
two
card size
one low-profile card and one full-height card
connector size
120 pins
connector data width
(maximum)
32 bits
PCI Express
connectors
one x16
card size
full-height
power
25 W maximum
connector size
164 pins (x16)
connector data width
(maximum)
16 PCI Express lanes (x16)
PCI only: with optional, full-height
PCI riser-card cage, supporting
both low-profile and full-height
cards
connectors
three PCI
card size
one low-profile card and two full-height cards
connector size
120 pins
connector data width
(maximum)
32 bits
eSATA
Expansion Bus
