Upgrade Kits
NOTE: Kit includes SATA, SAS, and PCIe cables. The cables are required based on configurations and not all cables are
required for a configuration.
Table 65. Upgrade kits
Kits Related links to service instructions
PERC H755 MX See Installing the H755 MX card
PERC H965 MX See Installing the H965 MX card
HBA350i MX See Installing the HBA350i MX card
1. Identify the backplane (see column Backplane configuration in the table).
Figure 120. x6 universal backplane
Figure 121. x4 universal backplane
8
Upgrade Kits 141
