Dell PowerEdge MX760c - Hba350 I MX Upgrade Kit

Table 67. PERC H965 MX upgrade kit (continued)
Backplane
configuration
Upgrade from: Upgrade to: Disconnect and
remove card or
cables from the
connector (cable
marking):
Replace with the
card or cables
(cable marking):
Refer to cabling
configurations
x8 EDSFF
backplane
Onboard NVME H965 MX (NVMe)
● PCIE1 cable
(MB SL1 – BP
PA1)
● PCIE2 cable
(MB SL2 – BP
PB1)
● PCIE4 cable
(MB SL4, MB
SL5 – BP PA2,
BP PB2)
● H965 MX card
● PCIEA cable
(CTRL_PA1 –
BP PA1 and BP
PB1)
● PCIEB cable
(CTRL_PB1 –
BP PA2 and BP
PB2)
Cable routing
> SAS cabling
diagram of
configuration 14 -
8 x E3.s backplane
with H755 MX or
H965i MX
HBA350i MX Upgrade kit
The below table provides the upgrade kit information about HBA350i MX available After Point of Sale (APOS):
Table 68. HBA350i MX upgrade kit
Backplane
configuration
Upgrade from: Upgrade to: Disconnect and
remove card or
cables from the
connector (cable
marking):
Replace with the
card or cables
(cable marking):
Refer to cabling
configurations
X4 Universal
backplane
Onboard SATA/
SWRAID/NVME
HBA350i
(SAS Controller/
Non–RAID)
SATA cable (MB
SL3 – BP SA1)
● HBA350i MX
card
● SAS cable
(CTRL_SA1–BP
SA1)
Cable routing
> SAS/PCIe
cabling diagram
of configuration 7
- 4 x 2.5-inch
universal backplane
with HBA350i MX
X6 SAS/SATA
backplane
Onboard SATA/
SWRAID
HBA350i
(SAS Controller/
Non–RAID)
SATA cable (MB
SL3 – BP SA1)
● HBA350i card
● SAS cable
(CTRL_SA1–BP
SA1)
Cable routing
> SAS/PCIe
cabling diagram of
configuration 4 -
6 x 2.5-inch SAS/
SATA backplane
with HBA350i MX
Upgrade Kits 145
