Dell PowerEdge MX760c - Chapter 3: Technical Specifications; Sled Dimensions

Technical specifications
The technical and environmental specifications of your system are outlined in this section.
Topics:
• Sled dimensions
• Sled weight
• Processor specifications
• Supported operating systems
• System battery specifications
• Memory specifications
• PERC, Mezzanine and Mini Mezzanine slots specifications
• Drives
• Storage controller specifications
• Ports and connectors specifications
• Video specifications
• Environmental specifications
Sled dimensions
Figure 17. Sled dimensions
Table 1. PowerEdge MX760c sled dimensions
System configuration X Y Z (handle closed).
4 x 2.5-inch or 6 x 2.5-inch 257.0 mm (10 inches) 51.0 mm (2 inches) 622.35 mm (24.5
inches)
8 x E3.s 257.0 mm (10 inches) 51.0 mm (2 inches) 631.77 mm (24.8
inches)
3
18 Technical specifications
