Before working inside your system
Prerequisites
Follow the safety guidelines listed in the Safety instructions.
Steps
If applicable install the I/O connector cover.
CAUTION: To prevent damage to the I/O connectors on the system, ensure that you cover the connectors when
you remove the system from the enclosure.
After working inside your system
Prerequisites
Follow the safety guidelines listed in Safety instructions.
Steps
1. If applicable, remove the I/O connector cover from the system connectors. Install the sled into the enclosure.
2. Reconnect the peripherals and connect the system to the electrical outlet, and then power on the system.
Recommended tools
You may need some or all of the following tools to perform the removal and installation procedures:
● Phillips 1 screwdriver
● Phillips 2 screwdriver
● Torx T30 screwdriver
● 5 mm hex nut screwdriver
● Plastic scribe
● 1/4-inch flat blade screwdriver
● Wrist grounding strap connected to the ground
● ESD mat
● Needle-nose pliers
You need the following tools to assemble the cables for a DC power supply unit:
● AMP 90871-1 hand-crimping tool or equivalent
● Tyco Electronics 58433-3 or equivalent
● Wire-stripper pliers to remove insulation from size 10 AWG solid or stranded, insulated copper wire
NOTE: Use alpha wire part number 3080 or equivalent (65/30 stranding).
PowerEdge MX760c sled
The PowerEdge MX760c sled is a server unit that is installed into the PowerEdge MX7000 enclosure.
Removing the sled from enclosure
Prerequisites
1. Follow the safety guidelines listed in Safety instructions.
2. Power off the sled.
