Table 16. MX760c component configurations that require a thermally optimized chassis (continued)
Component description
MOD MDW67 MOD, INFO, HIGH PERFORM COMPONENT
MX7000 chassis upgrade requirement:
1. MX7000 Gold Grade (Hardware version 2, Gen2) fans (customer kit PN: H2YC5/SKU: SKU 750-ADWN; included in MX
solutions orders with MX760c)
2. OME-M (OpenManage Enterprise - Modular) FW 2.00.00.
(scan the QR code to download the firmware)
3. iDRAC FW 05.10.25/06.10.05
(scan the QR code to download the drivers on sleds installed in MX7000 chassis)
4. Enterprise Infrastructure Planning Tool (EIPT)
(scan the QR code to access the EIPT)
NOTE:
When selecting or upgrading the system configuration, to ensure optimum power utilization, verify the system
power consumption with the Enterprise Infrastructure Planning Tool available at Dell.com/calc.
NOTE: To generate the thermally optimized sled-to-slot assignments, enter the MX configuration in the EIPT tool and click
Optimize
To setup the sled:
1. Power off the MX7000 chassis.
2. Install the eight, MX760csleds at front of the enclosure.
3. Install the four, 60 mm gold grade (Gen 2) fans at the front and the five, 80 mm gold grade (Gen 2) fans at the rear of the
MX7000 chassis
4. To verify if correct gold grade fans are installed, use one of the following methods:
Physical Verification:
1. Identify the Gold Grade silksreen on the fan module
Initial system setup and configuration
27
