WallWall
- Failure to comply with above mounting instructions including permitted
orientations and designated clearances may result in derated power output
and may void the warranty. To avoid these issues follow the instructions above!
CAUTION !
Figure 3-8: Separation distance of plural inverters
* If the installation location has a risk of flooding or accumulated snow, please raise the appropriate
height of the inverter.
When mounted back to back, clapboards
must be installed on both sides.
>300 mm>300 mm
>200 mm >200 mm
>600 mm
>150 mm * >150 mm *
300 mm
300 mm
200 mm
> 50 mm
24
Installation
