Delta VFD-L Series User Manual

5
VFD-L Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
5-1
CHAPTER 5 DESCRIPTION OF PARAMETER SETTINGS
Group 0: User Parameters
0 - 00
I
dentity Code of AC Motor Drive
F
actory setting: d #
Settings None
Watts / hp 40W 100W 1/4hp 1/2hp 1hp 2hp
115V / 230V d 1 d 2 d 3 d 4 d 5 d 6
 This parameter shows the capacity of the AC drive. Users can read Pr.0-01 to check if it
is the rated current of the AC drive corresponds to the identity code shown above and
the current shown below.
0 - 01
R
ated Current Display of the AC drive
F
actory Setting: d ##.#
Settings None Unit: 0.1A
V / HP 40W 100W 1/4hp 1/2hp 1hp 2hp
115V / 230V 0.4A 0.8A 1.6A 2.5A 4.2A 7.0A
 This parameter displays the rated current of the AC drive. It will display based on Pr.0-00,
and is read-only.
0 - 02
P
arameter Reset
F
actory Setting: d 0
Settings d 0 to d 9 Not used
d 10 All parameters are reset to be factory settings
 This setting allows the user to return all parameters to the factory default settings.
0 - 03
S
tart-up Display Selection
F
actory Setting: d 0
Settings d 0 Display the Master Frequency (F)
d 1 Display the actual operation frequency (H)
d 2 Display the content of users-defined unit
d 3 Display the output current (A 
This parameter can be set during operation.

Delta VFD-L Series Specifications

General

Control Method	V/F Control
Output Voltage	0 to Input Voltage
Cooling Method	Fan Cooling
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection	Over-voltage, Over-current, Overheat, Under-voltage, Short circuit
Braking Unit	Built-in
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Digital Inputs	5 programmable digital inputs
Analog Input	0-10V, 4-20mA
Communication Interface	RS-485 (Modbus)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	90% RH, non-condensing
Altitude	Up to 1000m without derating
Input Voltage	200-240V, 380-480V
