Delta VFD-L Series User Manual

VFD-L Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-4
P
aramete
rs
Functions Settings
Factor
y
settin
g
4-04
Multi-function input
terminal1 (M0, M1)
(d 0

d 20)
1
4-05
Multi-function input
terminal 2(M2)
6
Multi-function input
terminal 3(M3)
7
(d 0, d 4

d 20)
4-06
0: not used
1: M0: FWD/STOP, M1:REV/STOP
2: M0: FWD/REV, M1:RUN/STOP
3: M0, M1, M2: 3-wire operation contr
ol
mode
4: External fault, normally open (N.O.)
5: External fault, normally closed (N.C.)
6: RESET
7: multi-step speed command 1
8: multi-step speed command 2
9: jog operation
10: accel/decel speed inhibit
11: first or second accel/decel time selectio
n
12: base-block (B.B.),normally open (N.O.)
13: base-block (B.B.),normally closed (N.C
)
14: increase master freq.
15: decrease master freq.
16: run PLC program
17: pause PLC
18: counter trigger signal
19: counter reset
20: select ACI/deselect AVI
Group 5: Multi-step Speed and PLC Parameters
Parameter
s
Functions Settings
Factor
y
Settin
g
5-00 1
st
step speed freq. 0.0 ~ 400Hz 0.0
5-01 2
nd
step speed freq. 0.0 ~ 400Hz 0.0
5-02 3
rd
step speed freq. 0.0 ~ 400Hz 0.0
5-03 PLC mode 0: Disable PLC operation
1: Execute one program cycle
2: Continuously execute program cycles
3: Execute one program cycle step b
y
step (separate by STOP)
4: Continuously execute one progra
m
cycle step by step (separate b
y
STOP)
0
5-04 PLC forward/revers
e
motion
0 ~ 15 (0: Forward 1: Reverse) 0
5-05 Time duration step 0 0 ~ 65500 Sec 0
5-06 Time duration step 1 0 ~ 65500 Sec 0
5-07 Time duration step 2 0 ~ 65500 Sec 0
5-08 Time duration step 3 0 ~ 65500 Sec 0

Delta VFD-L Series Specifications

General

Control Method	V/F Control
Output Voltage	0 to Input Voltage
Cooling Method	Fan Cooling
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection	Over-voltage, Over-current, Overheat, Under-voltage, Short circuit
Braking Unit	Built-in
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Digital Inputs	5 programmable digital inputs
Analog Input	0-10V, 4-20mA
Communication Interface	RS-485 (Modbus)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	90% RH, non-condensing
Altitude	Up to 1000m without derating
Input Voltage	200-240V, 380-480V
