ver-Torque Detection Mode
F
actory Setting: d 0
Settings d 0 Over-Torque detection disabled.
d 1 Over-Torque detection enabled during constant speed
operation (OL2), and operation continues until the
continuous operation limit (Pr.6-04) is reached.
d 2 Over-Torque detection enabled during constant speed
operation, and operation halted after over-torque
detection.
d 3 Over-Torque detection enabled during acceleration, and
operation continues before the Continuous Output Time
Limit (Pr.6-04) is reached.
d 4 Over-Torque detection enabled during acceleration.
Operation halted after over-torque detection
6 - 03
O
ver-Torque Detection Level
F
actory Setting: d 150
Settings d 30 to d 200% Unit: 1%

A setting of proportional to the Rated Output Current of the drive.
6 - 04
C
ontinuous Output Time Limit
F
actory Setting: d 0.1
Settings d 0.1 to d 10.0 sec Unit: 0.1sec

This parameter determines the time that AC drive will run after over-torque is detected.
Over-torque detection is based on the following:
If a Multi-Function Output Terminal is set as Over-Torque Detection Indication and the
output current exceeds the Over-Torque Detection Level (Pr.6-04, Factory Setting:
150%), the output will be activated.
6 – 05
E
lectronic Thermal Overload Relay Selection Factory Setting: d 0
Settings d 0 Not used
d 1 Act with standard motor
d 2 Act with special motor

This function is used to limit the output power of the AC drive when powering a
“self-cooled motor” at low speed.

Delta VFD-L Series Specifications

General

Control Method	V/F Control
Output Voltage	0 to Input Voltage
Cooling Method	Fan Cooling
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection	Over-voltage, Over-current, Overheat, Under-voltage, Short circuit
Braking Unit	Built-in
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Digital Inputs	5 programmable digital inputs
Analog Input	0-10V, 4-20mA
Communication Interface	RS-485 (Modbus)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	90% RH, non-condensing
Altitude	Up to 1000m without derating
Input Voltage	200-240V, 380-480V
