Delta VFD-L Series User Manual

2
VFD-L Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
2-1
CHAPTER 2 STORAGE AND INSTALLATION
2.1 Storage
The AC drive should be kept in the shipping carton before installation. In order to retain the
warranty coverage, the AC drive should be stored properly when it is not to be used for an
extended period of time.
Ambient Conditions:
O
peration
A
ir Temperature: -10
o
C to +40
o
C (14
o
F to 104
o
F)
A
tmosphere pressure: 86 to 106 kPa
I
nstallation Site Altitude: below 1000m
V
ibration: Maximum 9.86 m/s
2
(1G) at less than 20Hz
Maximum 5.88 m/s
2
(1G) at 20Hz to 50Hz
S
torage
T
emperature: -20
o
C to +60
o
C (-4
o
F to 140
o
F)
R
elative Humidity: Less than 90%, no condensation allowed
A
tmosphere pressure: 86 to 106 kPa
T
ransportation
T
emperature: -20
o
C to +60
o
C (-4
o
F to 140
o
F)
R
elative Humidity: Less than 90%, no condensation allowed
A
tmosphere pressure: 86 to 106 kPa
V
ibration: Maximum 9.86 m/s
2
(1G) at less than 20Hz, Maximum 5.88
m
/s
2
(1G) at 20Hz to 50Hz
P
ollution Degree
2
: good for a factory type environment.

Delta VFD-L Series Specifications

General

Control Method	V/F Control
Output Voltage	0 to Input Voltage
Cooling Method	Fan Cooling
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection	Over-voltage, Over-current, Overheat, Under-voltage, Short circuit
Braking Unit	Built-in
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Digital Inputs	5 programmable digital inputs
Analog Input	0-10V, 4-20mA
Communication Interface	RS-485 (Modbus)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	90% RH, non-condensing
Altitude	Up to 1000m without derating
Input Voltage	200-240V, 380-480V
