Group 5: Multi-step Speed, Process Logic Control Parameters
5 - 00
1
st Step Speed Frequency
F
actory Setting: d 0.0
5 - 01
2
nd Step Speed Frequency
F
actory Setting: d 0.0
5 - 02
3
rd Step Speed Frequency
F
actory Setting: d 0.0
Settings d 0.0 to d 400 Hz Unit: 0.1Hz
This parameter can be set during operation.
 The Multi-Function Input Terminals (refer to Pr.4-04 to 4-06) are used to select one of
the AC drive Multi-Step speeds. The speeds (frequencies) are determined by Pr.5-00
to 5-02 shown above.
5 – 03
P
LC Mode Factory Setting: d 0
Settings d 0 Disable PLC operation
d 1 Execute one program cycle
d 2 Continuously execute program cycles
d 3 Execute one program cycle step by step
d 4 Continuously execute program cycles step by step

This parameter selects the mode of PLC operation for the AC drive. The PLC program
can be used in lieu of any External Controls, Relays or Switches. The AC drive will
change speeds and directions according to the user’s desired programming.
Example 1 (Pr.5-03 = d1): Execute one cycle of the PLC program. Its relative parameter
settings are:
1. Pr.5-00 to 5-02: 1
st
to 3
rd
step speed

sets the frequency of each step speed

2. Pr.4-04 to 4-06: Multi-Function Input Terminals

set one multi-function terminal as d16-
PLC auto-operation

.
3. Pr.3-03: Multi-Function Output (set the relay as d10-PLC operation indication, d11-one
cycle in PLC auto mode or d12-PLC operation fulfillment attainment).
4. Pr.5-03: PLC mode.
5. Pr.5-04: Direction of operation for Master Frequency and 1
st
to 3
rd
step speed.
6. Pr.5-05 to 5-08: operation time setting of Master Frequency and 1
st
to 3
rd
step speed.

Delta VFD-L Series Specifications

General

Control Method	V/F Control
Output Voltage	0 to Input Voltage
Cooling Method	Fan Cooling
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection	Over-voltage, Over-current, Overheat, Under-voltage, Short circuit
Braking Unit	Built-in
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Digital Inputs	5 programmable digital inputs
Analog Input	0-10V, 4-20mA
Communication Interface	RS-485 (Modbus)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	90% RH, non-condensing
Altitude	Up to 1000m without derating
Input Voltage	200-240V, 380-480V
