8 - 15
A
utomatic Voltage Regulation (AVR)
Factory Setting: d 2
Settings d 0 AVR function enabled
d 1 AVR function disabled
d 2 AVR function disabled when deceleration
AVR function automatically regulates the AC drive output voltage to the Maximum Output
Voltage (Pr.1-02). For instance, if Pr.1-02 is set at 200 VAC and the input voltage is at
200V to 264VAC, then the Maximum Output Voltage will automatically be regarded to 200
VAC.
Without AVR function, the Maximum Output Voltage may vary between 180V to 264VAC,
due to the input voltage varying between 180V to 264 VAC.
Selecting program value d2 enables the AVR function and also disables the AVR function
during deceleration. This offers a quicker deceleration.
8 - 16
D
ynamic Braking Voltage
F
actory Setting: d 380*
Settings d 350 to d 450V* Unit: 1Volt*
During deceleration, the DC-bus voltage will increase due to motor regeneration. When
DC bus voltage level exceeds the Dynamic Braking Voltage, the DC brake output pins
(B1, B2) will be activated.
8 - 17
D
C Braking Lower Bound Limit
Factory Setting: d 0.0
Settings d0.0 to d400 Hz Unit: 0.1Hz
The setting frequency is lower than Pr.8-17, the DC Braking will not be activated when
stops.
