Delta VFD-L Series User Manual

8
VFD-L Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-1
CHAPTER 8 SUMMARY OF PARAMETER SETTINGS
Group 0: User Parameters
= The parameter may be set during operation.
P
aramete
rs
Functions Settings
Factor
y
Settin
g
0-00
Identity code of drive
(Read only)
1: 40W
2: 100W
3: 200W
4: 400W
5: 750W
6: 1.5KW
0-01
Rated current display
(Read only)
40W: 0.4A
100W: 0.8A
200W: 1.6A
400W: 2.5A
750W: 4.2A
1.5K: 7.0A
0-02 Parameter reset 10: Reset Parameters to Factory Settin
g
0
=
0-03 Start-up display of AC
drive
0: F (Frequency command)
1: H (output frequency)
2: U (user-defined unit)
3: A (output current)
0
=
0-04 User-defined Unit
0: Display User-Defined Unit (u)
1: Display Counter Value (C)
2: Display Process Operation (1=tt)
3: Display DC-BUS voltage (U)
4: Display output voltage (E)
0
=
0-05 User-defined coefficie
nt
K
0.1 ~ 160
1.0
0-06 Software version Read only #.#
0-07 Password input 0 ~ 999 0
0-08 Password configuration 0 ~ 999 0
Group 1: Basic Parameters
P
aramete
rs
Functions Settings
Factor
y
Settin
g
1-00
Maximum operation
Freq.
50.0 ~ 400Hz 60.0
1-01 Maximum setting Freq. 10.0 ~ 400Hz 60.0
1-02 Maximum output voltag
e
2.0 ~ 255V 220
1-03 Mid-point freq. 1.0 ~ 400Hz 1.0
1-04 Mid-point voltage 2.0 ~ 255V 12.0
1-05 Minimum output freq. 1.0 ~ 60.0Hz 1.0

Delta VFD-L Series Specifications

General

Control Method	V/F Control
Output Voltage	0 to Input Voltage
Cooling Method	Fan Cooling
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection	Over-voltage, Over-current, Overheat, Under-voltage, Short circuit
Braking Unit	Built-in
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Digital Inputs	5 programmable digital inputs
Analog Input	0-10V, 4-20mA
Communication Interface	RS-485 (Modbus)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	90% RH, non-condensing
Altitude	Up to 1000m without derating
Input Voltage	200-240V, 380-480V
