3.5 Address list:
The contents of available addresses are shown as below:
Content
Address
Functions
AC drive Parameters ggnnH gg means parameter group, nn means paramete
r
number, for example, the address of Pr 4-01 is
0401H. Referencing to chapter 5 for the function
of each parameter. When reading parameter by
command code 03H, only one parameter can be
read at one time.
Bit 0-1 00: No function
01: Stop
10: Run
11: Jog + Run
Bit 2-3 Not used
2000H
Bit 4-5
00: No function
01: FWD
10: REV
11: Change direction
Bit 6-15 Not used
2001H Freq. command
Bit 0 1: EF (external fault) on
Bit 1 1: Reset
Command
2002H
Bit 2-15 Not used
Error code:
0: No errors occurred
1: Over-current (oc)
2: Over-voltage (ov)
3: Overheat (oH)
5: Overload1 (oL1)
6: External fault (EF)
7: CPU failure (cF3)
8: Hardware protection failure (HPF)
9: Current exceeds 2 times rated current durin
g
accel (ocA)
Status monitor
Read only
2100H
10: Current exceeds 2 times rated current during
decel (ocd)

Delta VFD-L Series Specifications

General

Control Method	V/F Control
Output Voltage	0 to Input Voltage
Cooling Method	Fan Cooling
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection	Over-voltage, Over-current, Overheat, Under-voltage, Short circuit
Braking Unit	Built-in
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Digital Inputs	5 programmable digital inputs
Analog Input	0-10V, 4-20mA
Communication Interface	RS-485 (Modbus)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	90% RH, non-condensing
Altitude	Up to 1000m without derating
Input Voltage	200-240V, 380-480V
