Protocol 3
TM
User Guide E105, 313327, REV A
©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other
countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form
or by any means without the written permission from ITW EAE, unless for purchaser's personal use.
6.5.2. File Naming Conventions
The Protocol 3 controller names the first recorder log file 000001‐1.csv. Each time
the recording parameters are changed, a new file is created. For instance,
changing the recording parameters two times would produce these file names:
• 000002-1.csv
• 000003-1.csv
Note that:
• Stopping or starting a recording does not create a new file.
• For any file exceeding 65,500 data lines, the Protocol 3 controller creates a
new file with the last digit incremented by 1, for instance: 000001-2.csv,
then 000001-3.csv.
During Data Transfer, normal operation carries on in the
background but operator access to other screens is not possible.
Transfer of full memory can take up to 12 minutes. Begin a
transfer only when access (e.g. setpoint changes) will not be
required.
6.5.3. Create a New Name before Writing to the USB Device
Before writing a file (Write Recorder Log File, Write Profile File, Write
Configuration File), to the USB device, create a new name for the file or folder.
1. Insert the memory stick into the USB port.
2. For Enter USB Mode Unlock Code, press to reach 0010.
3. Press to display the Read/Write To USB Device? choices:
a. Write Recorder Log File
b. Read Profile File
c. Write Profile File
d. Read Configuration File
e. Write Configuration File
4. For Write Recorder Log File, press to display Enter a Folder Name.
