To set Two Point Calibration:
1. Use and to change the value of Calibration Low Temp. Press .
2. Use and to change the value of Calibration Low Offset. Press .
3. Use and to change the value of Calibration High Temp. Press .
4. Use and to change the value of Calibration High Offset. Press .
Example of Two Point Calibration:
With a controller set to Factory Calibration (no offset), suppose the following two
temperature reading situations exist:
• display on the control read 100 °C and the actual temperature measured
was 99 °C, and
• the display on the control read 200 °C and the actual temperature
measured was 195°C.
Then, enter the following settings for Two Point Calibration:
o Calibration Low Temp = 100, Calibration Low Offset = -1
o Calibration High Temp = 200, Calibration High Offset = -5
Return to the Main Menu by simultaneously pressing and .
6.6.3. Setting-up Remote Communication
Remote communication between the Protocol 3 controller and a PC running the
Despatch Protocol Manager software involves providing each controller with a
unique address and following the communication protocol procedures. Up to 32
separate controllers can be run from a PC running the Despatch Protocol Manager
software. See the Protocol Manager Instruction Manual for the complete set-up
procedure.
