Despatch PROTOCOL 3 User Manual

E105, 313327, REV A Protocol 3
TM
User Guide
10 of 82
©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other
countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form
or by any means without the written permission from ITW EAE, unless for purchaser's personal use.
2. SPECIFICATIONS
2.1. Process Input
Table 1. Process Input.
Item
Description
Sampling Rate:
4 per second
Resolution:
16 bits. Always four times better than display resolution.
Impedance:
>10MΩresistive, except DC mA (5Ω) and V (47kΩ)
Temp Stability:
Error <0.01% of span per °C change in ambient temperature
Supply Variation:
Supply voltage influence negligible within supply limits
Humidity Influence:
Negligible if non‐condensing
Process Display:
Displays up to 5% over and 5% under span limits
Process Variable
Input Offset:
Reading adjustable ± Controller Span. Values added to Process
Variable, Values subtracted from Process Variable.
Sensor Break
Detection:
• Thermocouple & RTD—SSR output goes to 0
• High Limit Sensor Break alarms activate
• Linear (4 to 20mA, 2 to 10V and 1 to 5V only)—SSR output
goes to 0
Isolation:
Isolated from all outputs (except SSR driver) at 240V AC
Supported
Thermocouple Types
& Ranges:
Type
Range °C
Range °F
B
+100 to 1824°C
+211 to 3315°F
C
0 to 2320°C
32 to 4208°F
D
0 to 2315°C
32 to 4199°F
E
-240 to 1000°C
‐400 to 1832°F
J
-200 to 1200°C
-328 to 2192°F *
K
‐200 to 1200°C
‐328 to 2192°F *
L
0 to 762°C
32 to 1402°F *
N
0 to 1399°C
32 to 2551°F *
PtRh
0 to 1850°C
32 to 3362°F
