Despatch PROTOCOL 3 - Figure 31. Older Model Serial Converter Schematic

Protocol 3
TM
User Guide E105, 313327, REV A
©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other
countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form
or by any means without the written permission from ITW EAE, unless for purchaser's personal use.
79 of 82
Figure 31. Older model serial converter schematic.
