E105, 313327, REV A Protocol 3
TM
User Guide
©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other
countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form
or by any means without the written permission from ITW EAE, unless for purchaser's personal use.
Table 16. Configuration Menu in Tabular Format.
Provide
primary
control and
high limit
settings
• Input Type: Thermocouples, PtRh, PT100, NI120,
amperages, voltages
• Engineering Units: °C, °F, °K, bar, %, %RH, pH, psi or
none
• Decimal Point Position: Nearest 1/10 or 1/100 for
DC inputs
• Scale Input Range (lower and upper limits): Min &
Max range. Minimum range by default.
• Input Filter Time: OFF-100 Sec
• Cold Junction Compensation: Disable/Enable
Control Input
Calibration
• Factory Calibration:
• Single Point Calibration: OFF, -400-+400°
• Two Point Calibration: Low Temp. Low Offset, High
Temp, High offset
• Input Type: Thermocouples, PtRh, PT100, NI120,
amperages, voltages
• Engineering Units: °C, °F, °K, bar, %, %RH, pH, psi or
none
• Decimal Point Position: Nearest 1/10 or 1/100 for
DC inputs
• Scale Input Range (lower and upper limits): Min &
Max range
• Input Filter Time: OFF-100 Sec
High Limit Input
Calibration
• High Limit Process Variable: -250
• Factory Calibration: Resets back to factory defaults
• Single Point Calibration: OFF, -400-+400°
• Two Point Calibration: Low Temp, Low Offset, High
Temp, High Offset
Set control
actions, PID
control
options and
setpoint
limits
• Reverse Action /Direct Action: Reverse applies
primary power when below setpoint
• Primary Proportional Band: From ON-Off control or
set width of band from 0.1 to 999.9
• Integral Time (Auto-Reset): 1 sec to 99 min 59 sec or
OFF
• Derivative Time (Rate): 1 sec to 99 min 59 sec or
OFF
• Primary Cycle Time: 0.5 sec to 512 sec
