5. Input unique file name: press to move right and to move left. Press
or navigate through numbers, uppercase letters and lower case
letters.
6. For Confirm Write?,
a. Press No to abort the process and return to the previous menu
b. Press Yes to continue to write the file or folder.
6.6. Configuration Menu
Configuration provides access to menus that allow for setting up 11 different
options:
1. Input: Input settings and calibrate for process and High Limit Inputs
2. Control
3. Output
4. Alarm
5. Power Fail Recovery
6. Comms. (Communication)
7. Recorder
8. Clock
9. Display
10. Lock Code Configuration
11. Reset to Defaults
Navigate the configuration menus options using the flowchart (Figure 26) or Table
16. Figure 26 shows the Protocol 3 Controller configuration options. Access the
Configuration from the Main Manu (Section 6.2.4):
1. Simultaneously press and .
2. Navigate to Configuration Menu using or
3. Press to Enter Configuration Menu Mode Unlock Code.
4. Press to reach 0010, the Mode Unlock Code.
5. Press to display the configuration choices.
6. Navigate to the desired option using and .
