2.4. Conformance Norms
Table 4. Conformance Norms.
Item
Description
EMI:
CE: Complies with EN61326
Safety Considerations:
CE: Complies with EN61010‐1. UL, cUL to UL61010C‐1. Pollution
Degree 2, Installation Category II
Front Panel Sealing:
IP65 rating. IP20 behind the panel. (IP rating not recognized /
approved by UL)
Front Panel Cleaning:
Wash with warm soapy water and dry immediately. Close the
USB cover (if fitted) before cleaning.
2.5. Display
Table 5. Display.
Item
Description
Display Type:
160 x 80 pixel, monochrome graphic LCD with a dual color
(red/green) backlight
Display Area:
66.54mm (W) x 37.42mm (H)
Display Characters:
0 to 9, a to z, A to Z, plus ( ) ‐ and _

Despatch PROTOCOL 3 Specifications

General

Brand	Despatch
Model	PROTOCOL 3
Category	Controller
Language	English
