6.6.2. Working with Calibration Offsets
Calibration offsets allow configuration for oven temperature variations. Enter
calibration offsets through the Configuration Menu and Input Configuration.
6.6.2.1. Access the Configuration Menu
To access the Configuration Menu and all sub-menus, the controller must be in its
Cycle Complete or Stopped state (that is, not running). If the controller is not in
the Stopped state, press to stop the controller before proceeding.
1. Press and together from the Select a Mode screen to access the
Main Menu.
2. From the Main Menu, navigate to and select (highlight) the Configuration
Menu. Press .
3. A prompt will appear to enter an unlock code. Enter the correct code (the
default code is 0010) with and then press to access the
Configuration Menu.
6.6.2.2. Working with Input Configuration
Input Configuration allows you to configure items associated with the Control
Input Setup, Control Input Cal., High Limit Input Setup and High Limit Input Cal.
Control calibration offset parameters are located in the Control Input Cal.
To work with Input Configuration:
1. Navigate from the Configuration Menu to and highlight Input
Configuration. Press .
2. Navigate to and select Control Input Cal. Press .
a. Three options present: Factory Calibration, Single Point Calibration,
Two Point Calibration.
b. Only one option can be active at any given time. The highlighted choice
becomes the active choice.
