Page #66 background image
E105, 313327, REV A Protocol 3
TM
User Guide
66 of 82
©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other
countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form
or by any means without the written permission from ITW EAE, unless for purchaser's personal use.
6.6.1.5. Glossary of Alarm Terms
Table 18. Glossary of Alarm Terms.
Term
Description
Alarm
Hysteresis
Alarm hysteresis is the deadband on the safe side of an alarm (that is, the side
of the alarm that is below the high alarm value or above the low alarm value).
The signal must pass through this deadband before the alarm deactivates.
Alarm Inhibit
(Not functional
on Firmware
2.3 or lower)
Alarm Inhibit prevents unwanted process or deviation alarm activation at
power-up or when the controller setpoint is changed. The alarm activation is
inhibited until a safe condition is present. The alarm operates normally from
that point on.
For example, when the alarm is inhibited, a low alarm will not activate at
power-up until the process value first rises above the alarm point than falls
back below.
Input Signal
Break Alarm
If the signal from the process value input is broken the process value will
display OPEN and the alarm will activate.
Loop Alarm
A loop alarm detects faults in the control feedback loop by continuously
monitoring process variable response to the control output(s). If one of the
five alarms is defined to be a loop alarm, it repeatedly checks if the PID
control output is at saturation. If saturation is reached (0% or 100% power for
single control type), an internal timer is started. Thereafter, if the output has
not caused the process variable to be corrected by a predetermined amount
(V) after time (T) has elapsed, the alarm becomes active.
Subsequently, the alarm repeatedly checks the process variable and the PID
output. When the process variable starts to change value in the correct sense
or when the PID output is no longer at the limit, the alarm is deactivated.
For PID control, the loop alarm time (T) can be automatic (twice the Integral
Time value) or set to a user defined value. Correct operation with the
automatic loop alarm time depends upon reasonably accurate PID tuning. The
user defined value is always used for On-Off control, and the timer starts as
soon as an output turns on.
The value of V depends on the input type. For Temperature inputs, V = 2°C or
3°F. For Linear inputs, V = 10 x LSD (Least Significant Digitsmallest
incremental value that can be show at the defined display resolution).
% Memory
Used Alarm
The Protocol 3 controller can record data at a set interval. If the percentage
selected of the memory capacity of the recorded data is exceeded the alarm
will activate.
