E105, 313327, REV A Protocol 3
TM
User Guide
©2021 ITW EAE. All rights reserved. Despatch is a registered trademark in the U.S. and other
countries. No part of the contents of this manual may be reproduced, copied or transmitted in any form
or by any means without the written permission from ITW EAE, unless for purchaser's personal use.
6.2.3. Profile Mode
Navigate to HLSP to set the High Limit Setpoint before running a profile. Use
Profile Mode to select and run profiles that are programmed into the unit (Figure
15). Press or to navigate, to select the highlighted profile. Press to
start profile. Press to stop the profile and to exit Profile Mode (profile
must be stopped to exit Profile Mode).
If you are unable to select a desired profile, verify that Remote
Profile Control is Disabled. When Remote Profile Control is
Disabled, the Select Profile to Start reads “Digital”
Status bar shows status of profile and segment.
