Frame descriptions Explicit Addressing Command frame - 0x11

XBee®-PRO 900HP/XSC RF Modules

131

Frame data fields Offset Example

64-bit destination address MSB 5 0x00

6 0x13

7 0xA2

8 0x00

9 0x01

10 0x23

11 0x84

LSB12 0x00

Reserved

0xFF

0xFE

Source endpoint 15 0xE8

Destination endpoint 16 0xE8

Cluster ID 17 0x00

18 0x11

Profile ID 19 0xC1

20 0x05

Broadcast radius 21 0x00

Transmit options 22 0x00

Data payload 23 0x54

24 0x78

25 0x44

26 0x61

27 0x74

28 0x61

Checksum 29 0xA6
