XSC firmware Electrical characteristics
XBee®-PRO 900HP/XSC RF Modules
186
Symbol Parameter Condition Min Typical Max Units
V
IL
Input low voltage All input signals -0.3 0.3 VCC V
V
IH
Inputhighvoltage All input signals 0.7
VCC
VCC+0.3 V
V
OL
Output low-level
voltage
Iout = Iout_Max 0.4 V
V
OH
Output high-level
voltage
Iout = Iout_Max -0.4
VCC
V
IL Input leakage current With pull-up resistors
disabled
1
40 400 nA
IO1 Output current Pins 2, 15 (DOUT, TX/PWR) 2 mA
IO2 Output current Pins 4, 12, 13 (DO3, CTS,
ON/SLEEP)
8 mA
1
S3B can have pull-ups enabled and still maintain low leakage current.
