INTRODUCTION
1.14 Asterisks in Programming
Asterisks display next to a programming option that is already selected. As shown in the example, options
that are selected to display the current programming selection have an asterisk next to the number. Those
thatarenotselectedsimplydisplaythenumber.IntheDevicesexample,keypads3,8,9,and15arenot
selected.IntheAreasexample,areas3,8,9,15,19,23,25,and31arenotselected.Inbothexamples
the numbers with asterisks are selected.
*1 *2 3 *4
*5 *6 *7 8 *13 *14 15 *16
9 *10 *11 *12
Devices
*29 *30 31 *32
*13 *14 15 *16
9 *10 *11 *12
25 *26 *27 *28
*1 *2 3 *4
*5 *6 *7 8 *21 *22 23 *24
*17 *18 19 *20
Areas
To select or deselect a number, simply enter the number using the digit keys on the keypad. This same
scheme is used when viewing the panel armed status and other programming and operational functions.
Remember to press the COMMAND key to display the rest of the device or area numbers.
