DMP Electronics XR500 SERIES Programming Guide

Digital Monitoring Products XR500 Series Canadian Programming Guide
28
SYSTEM OPTIONS
9.6
CRS ZONE TM: 4
Cross Zone Time
Enter the time allowed between zone faults. When zones are cross zoned, the same
zone or a second cross zoned zone must fault within this time in order for an alarm
report for both zones to be sent to the receiver. If the cross zone time expires
withoutthesecondzonefaulting,onlyazonefaultfromtherstzoneisreported.
Cross-zonetimecanbefrom4to250seconds.Entering0(zero)disablesthis
function. Default is 4. See the Appendix.
9.7
RETARD DELAY: 10
Zone Retard Delay
Enter the retard time assigned to Fire, Supervisory, Auxiliary 1, Auxiliary 2, Arming,
and Panic type zones. The retard delay only functions when the zone is shorted.
The zone must remain shorted for the entire length of the Retard Delay before being
recognized by the panel. The Zone Retard Delay can be from 1 to 250 seconds.
Enteringa0(zero)disablesthisfunction.
9.8
PWR FAIL HRS: 1
Power Fail Delay
This option tracks the duration of an AC power failure. When the AC power is off for
the length of the programmed delay time, an AC power failure report is sent to the
receiver.Thedelaytimecanbefrom1to15hours.Enteringa0(zero)sendsthe
powerfailurereportaftera15-seconddelay.Thedefaultsettingis1.
9.9
SWGRBYPS TRIPS: 2
Swinger Bypass Trips
Enterthenumberoftimes(1-6)azonecangointoanalarmortroublecondition
within one hour be fore being auto matically bypassed. You can select one or two
trips. Bypassed zones are auto matically reset when the area they are assigned to is
disarmed.All24-hourzonesareresetwhenanyareaofthesystemisdisarmed.A
programmingStopoperationrestoresabypassedzone.Entering0(zero)disables
this function. Default is 2.
How it works
The panel hour timer starts at 59 minutes past the hour. If the hour timer expires
beforethetripcounterisexceeded,thetripcounterreturnsto0(zero).Ifthetrip
counter is exceeded before the hour expires, the zone is auto matically bypassed by
the panel. A Bypass Re port is sent to the receiver if Bypass Re ports is YES.
9.10
RST SBYP NO YES
Reset Swinger Bypass
When YES is selected, an auto matically bypassed zone is reset if it remains in a
normal condition for one complete hour after being bypassed. A report of the
automatic reset is sent to the receiver if Bypass Reports has been se lected as YES.
Default is NO.
9.11
TIME CHG NO YES
Time Zone Changes
This function allows the panel to request automatic time changes from the DMP
SCS-1RReceiveronPath1.Forthereceivertosendtimechanges,itmustbe
programmed to send time changes and must be receiving time change updates from
the network automation computer at least every 24 hours. Default is YES.
HRS FROM GMT: 6
WhentimezoneisprogrammedYES,enterthenumber(0-23)thatindicatesthe
GreenwichTimezone(GMT)wherethepanelislocated.Thedefaultis6.
GMT City/Time Zone GMT City/Time Zone
0 London, Monrovia, Lisbon, Dublin, Casablanca, Edinburgh 13 New Cadelonia
1 Cape Verde Island, Azores 14 Guam, Sydney
2 Mid-Atlantic, Fernando de Noronha 15 Tokyo, Seoul
3 Buenos Aires, Georgetown, Brasilia, Rio de Janeiro 16 Hong Kong, Singapore
4 Atlantic Time (Canada), Caracas, La Paz, Santiago 17 Bangkok, Hanoi
5 Eastern Time (US, Canada) Bogota, Lima, Arequipa 18 Dhaka, Almaty
6 Central Time (US, Canada), Mexico City, Saskatchewan 19 Islamabad, Karachi
7 Mountain Time (US, Canada), Edmonton 20 Abu Dhabi, Kazan
8 Pacic Time (US, Canada), Tijuana 21 Moscow, Bagdad
9 Alaska 22 Eastern Europe
10 Hawaii 23 Rome, Paris, Berlin
11 Midway Island, Samoa
12 Fiji, Marshall Island, Wellington, Auckland, Kwajalein, Kamchatka
