DMP Electronics XR500 SERIES Programming Guide

XR500 Series Canadian Programming Guide Digital Monitoring Products
59
ZONE INFORMATION
FOLLOW - The output is turned on and remains on while the zone is in an off
normal, or bad condition. When the zone restores, the output is turned off.
Note: For Day Zone types, when an output is turned on, a user code with silence
authority can turn the output off.
After you make the three selections in the sections above, the display prompts you
for the same three selections for Disarmed Short, Armed Open, and Armed Short
conditions.Ifthezoneisa24-hourtype,onlytheArmedOpenandArmedShort
conditions display. When you have programmed all of the zone conditions, the
Swinger Bypass selection then dis plays.
19.18
SWGR BYP NO YES
Swinger Bypass
Selecting YES allows the zone to be swinger bypassed by the panel according to the
specications programmed in Swinger BypassTrips and Reset SwingerBypass.The
Bypass conditiondisplaysin the keypad StatusList. Selecting NO disablesswinger
bypassing for this zone.
How it works
Ifwithinonehour,azonetripsthetotalnumberoftimesasspeciedinSwinger
Bypass Trips, the panel bypasses it until the following conditions occur; the area
in which the zone is assigned is disarmed, the zone is manually reset through the
BypassZones?keypadUserMenufunction,thezoneremainsnormalforonehourand
the Reset Swinger Bypass is YES.
Ifthezonetripsfewerthanthespeciedtimeswithinonehour,thebypasstrip
counterreturnsto0(zero)andtheprocessmustberepeated.
A report of the swinger bypass is sent to the receiver if Bypass Reports is YES.
19.19
PREWARN KEYPADS:
Prewarn Keypad Addresses
Attheentrydelaystart,allkeypadaddressesselectedheredisplayENTERCODE:-.
Ifyouwanttheprewarntosoundatall16addresses,leavethedefaultsetting.
To delete an address, press the matching number on the keypad. To disable
prewarning at all keypads, press a top row Select key to clear the addresses shown.
Press the COM MAND key when the address selection is com plete.
Theprewarntonestopsatthekeypadwheretherstusercodedigitisentered.If
nokeysarepressedforvesecondsoraninvalidusercodeisentered,theprewarn
tone resumes at that keypad.
19.20
ENTRY DELAY: 1
Entry Delay
Select the entry timer for this zone. Entry timers 1 to 4 are programmed in System
Options.
19.21
RETARD NO YES
Zone Retard Delay
When you select YES, the zone operates with the zone retard delay. The retard
func tions only in zone short condi tions.
The zone must re main shorted for the full length of the re tard de lay before the
panel recognizes its condition. If you select NO, the zone operates without a retard
delay.
19.22
PRESGNL KEYPADS:
Presignal Keypad Addresses
You can enable any combina tion of keypad addresses to sound a presignal tone
during the time a zone is in retard delay. The presignal tone si lences when the zone
restores or the re tard delay expires.
To en able a presignal ad dress, press any top row Select key followed by the number
ofthekeypadaddress.Youcanenablethepresignalforall16keypadaddresses.
To disable a presignal address press the matching number digit again. Press the
COMMAND key when the address selection is complete. The Presignal prompt is only
displayed when Retard is selected as YES.
19.23
FAST RSP NO YES
Fast Response
SelectYEStoprovideazoneresponsetimeof167ms.SelectNOtoprovideanormal
zoneresponsetimeof500ms.Zones500to999haveaxedresponsetimeanddo
not display this prompt.
