DMP Electronics XR500 SERIES Programming Guide

XR500 Series Canadian Programming Guide Digital Monitoring Products
21
DEVICE SETUP
734 Site Code Programming
6.18.9 Site Code Position
Enter the site code start position in the data string. Press any top row Select
keytoenteranumberbetween1-255.Defaultis1.
6.18.10 Site Code Length
Enter the number of characters the site code contains. Press any top row
Selectkeytoenteranumberbetween1-16.Defaultis8.
6.18.11
USER CODE
POSITION: 9
User Code Position
DenetheUserCodestartbitposition.PressanytoprowSelectkeyto 
enteranumberbetween0-255.Defaultis9.
6.18.12
USER CODE
LENGTH: 16
User Code Length
DenethenumberofUserCodebits.PressanytoprowSelectkeytoenter 
acustomnumber.Customnumberscanonlybeanumberbetween16-32. 
Ona734N / 734N-WiFiModule,customnumberscanbebetween1-255.
Thedefaultis16.
6.18.13
REQUIRE SITE
CODE? NO YES
Require Site Code
Press the top row Select key under YES to use a site code.
InadditiontoUserCodeverication,dooraccessisonlygrantedwhenanyonesite
code programmed at the SITE CODE ENTRY option matches the site code received in
the Wiegand string.
6.18.13 .1
SITE CODE 1: -
Site Code Display
734 Module: Youcanprogramupto8three-digitsitecodes.Sitecode
 rangeis0-999.Anypreviouslyprogrammedsitecodesdisplay.Dashes
represent blank site codes. Default is blank.
Note: A card with a site code greater than three digits cannot be used.
Use only cards with three-digit site codes.
734N/734N-WiFi Module:Youcanprogramupto8ve-digitsitecodes.Site
 coderangeis1-65535.Anypreviouslyprogrammedsitecodesdisplay.Site
 Code1defaultsto127.SiteCodes2-8defaulttoblank.Dashesrepresent
blank site codes.
 SiteCode1displaysrst.Enterasitecodenumberfollowedbythe 
Command key to advance to the next prompt, Site Code 2. To delete an
existing site code, press any Select key. Either enter a new site code
followed by Command, or press Command to leave blank and continue to
 thenextsitecode.Repeatthesestepstochange,delete,oraddupto8site
codes.
6.18.14
NO OF USER CODE
DIGITS: 5
Number of User Code Digits
The734modulerecognizesusercodesfrom4-10digitsinlength.The734N / 734N-WiFi
modulerecognizesusercodesfrom1-10digitsinlength. Press any top row Select key
toenterausercodedigitlengthbetween4-10digits.Thisnumbermustmatchthe
user code number length being used by the panel. Default is 5. For an XR500 Area
System,use4to10digits(typically5).Forallothersystemsandpanels,use4digits.
Anyselectionabove5digitsrequireentryofthecustomcarddenitionswithcustom
site and user code positions for the Wiegand string. When searching the bit string
fortheusercode,thedigitsareidentiedandreadfromlefttoright.
SITE CODE
POSITION: 1
SITE CODE
LENGTH: 8
SITE CODE 1:
(1-65,535) 127
01110101101101010001100111
First Bit
Received
Position = 0
Site Code
Position = 1
Length = 8
User Code
Position = 9
Length = 16
Last Bit
Received
Position = 25
In this example the Wiegand Code Length = 26 bits.
