DMP Electronics XR500 SERIES Programming Guide

Digital Monitoring Products XR500 Series Canadian Programming Guide
36
OUTPUT OPTIONS
11.15
CLS WAIT OUT: 0
Closing Wait Output
Entertheoutputnumbertoturnonforapproximatelyfour(4)secondswhenClosing
Wait is programmed as YES and the panel successfully communicates the closing
message at arming. If the closing message does not communicate successfully, this
output does not turn on.
11.16
ARM-ALARM OUT: 0
Arm-Alarm Output
Enter the output number to turn on steady when any area of the system is armed. If
an alarm occurs causing the keypads to turn Red, this output pulses and continues to
pulseforapproximatelyve(5)minutesafterthepanelisdisarmed.Enter0(zero)
to disable.
Wireless Outputs
• TheArm-AlarmOutputiscompatiblewiththeModel1117WirelessLED
AnnunciatorandtheModel1116WirelessRelayOutputconnectedtoaModel
572IndicatorLED.
• WhentheModel1117isbatteryoperated,theLEDisoffwhenthesystemis
armedtoconservebatterylife.Ifanalarmoccurs,theoutputashesquickly.
• WhenusingtheModel1116connectedtoaModel572,theLEDisonwhenthe
system is armed. If an alarm occurs, the output pulses.
• TooperatetheArm-Alarmoutputwithinonesecond,programafastresponse
numberfrom480to499.Fastresponseoperationreducesoverallwireless
output battery life.
• TooperatetheArm-Alarmoutputwithin15seconds,programaslowresponse
numberfrom450to474.Slowresponseoperationincreasesoverallwireless
output battery life.
11.17
SUPV ALM OUT: 0
Supervisory Alarm Output
Enter the output number to turn on when a supervisory zone type is placed into an
alarm. The output turns off when all supervisory type zones are restored to normal.
Enter0(zero)todisable.Defaultis0.
